Overview
You don't need to sacrifice mobility for connectivity. Take amazing studio-quality sound and flexible input options on the road with the PreSonus® Studio 1810c audio interface. With four of PreSonus' lauded XMAX analog mic preamps, high-quality instrument preamps, balanced line-level inputs, and an ADAT input to add eight more channels whenever you need them, the Studio 1810c is a compact recording powerhouse housed in a rugged, roadworthy chassis.
When you have the right tools, any job is easier and faster to finish. High-quality converters and PreSonus' professional-grade XMAX mic preamps enable you to capture complex musical harmonics smoothly and naturally, with no audible distortion. XMAX mic preamps deliver incredibly high headroom, deep lows, smooth highs, and a rich overall sound, so you'll hear every breath, transient, and detail in your recordings. Professional input and output metering let you keep an eye on your levels when you're recording by yourself. Easy-to-use DSP monitor mixing lets you create four discrete mixes for you and three others. Two pairs of outputs afford two different stereo mixes. The Cue A/B button allows you to toggle between each mix while listening in on headphones, great for dialing in monitor mixes from the control room.
When you need to be ready to create professional recordings anywhere, the Studio 1810c has you covered with superior mic preamps and expandable inputs to give you world-class results.
Overview
Features
- Simultaneous I/O up to 18 inputs/8 outputs (8x6 at 192 kHz)
- 2 mic/instrument/line inputs with XMAX Class A mic preamps
- 2 mic/line inputs with XMAX Class A mic preamps
- 4 balanced ¼-inch TRS direct-to-ADC line inputs
- 8 channels of ADAT Optical input (4 channels at 96 kHz)
- 2 balanced ¼-inch TRS main outputs and 2 balanced ¼-inch TRS line outputs for monitor mixing all DC coupled for sending control voltages
- High-power headphone output
- Stereo S/PDIF digital I/O and MIDI In/Out
- 18x6 onboard DSP monitor mixer
- Front-panel mute and level controls for main outputs
- 6 ladder-style 8-LED level meters (4 input, 2 main output)
- 24-bit resolution, 44.1, 48, 88.2, 96, 176.4 and 192 kHz sampling rates
- USB-C to USB-C and USB-C to USB-A cables included for compatibility with most computers
- Professional Recording Software Included - Fender Studio Pro License
Downloads
Don't see what you're looking for?
Log in to your my.presonus.com account.
- Universal Control v5.0 (Android)
- Universal Control v5.0 Download (Mac)
- Universal Control v5.0 Download (Windows)
- Universal Control v4.7.2.108537 Download (Windows)
- Universal Control v4.7.2.108537 (Android)
- Universal Control v4.7.2.108537 Download (Mac)
- Universal Control v4.7.1.107907 Download (Mac)
- Need an older version? Click here
Don't see what you're looking for?
Log in to your my.presonus.com account.
Specs
Product Name
Studio 1810c, Black, 220-240V UK
Series
Studio
Color
Black
Connection Type
Combo Locking XLR Mic - 1/4” TRS Line
Frequency Response
20 Hz - 20 kHz (Unity Gain)
Input Impedance
1.4 kΩ
Dynamic Range
110 dB (A-Weighted, Minimum Gain)
EIN
-128 dBu (A-Weighted, 20 kHz BW, Rs=150Ω, Maximum Gain)
THD+N
0.005% (1 kHz, 0dBu, Unity Gain)
Gain Range
80 dB
Maximum Input Level
+16 dBu, Minimum Gain
Phantom Power
+48 VDC
Frequency Response
20 Hz - 20 kHz (Unity Gain)
Input Impedance
10 kΩ
Dynamic Range
112 dB (A-Weighted, Minimum Gain)
THD+N
0.005% (1 kHz, +18 dBu, Minimum Gain)
Gain Range
40 dB
Maximum Input Level
+21 dBu (balanced, Minimum Gain)
Frequency Response
20 Hz - 20 kHz (Minimum Gain)
Dynamic Range
112 dB (A-Weighted, Minimum Gain)
THD+N
0.020% (1 kHz, +10 dBu, Minimum Gain)
Gain Range
80 dB
Maximum Input Level
+15 dBu (Unbalanced, Minimum Gain)
Connection Type
1/4" TRS, Balanced
Connection Type
1/4" TRS, Balanced
Connection Type
1/4" TRS Active Stereo
Frequency Response
20 Hz - 20 kHz (Unity Gain)
Impedance Working Range
32Ω to 600Ω
Dynamic Range
103 dB (A-weighted, 1 kHz, Unity Gain)
THD+N
0.250% (1 kHz, 150 mW, Unity Gain)
Maximum Output Level
150 mW/Channel (60Ω Load)
Connection Type
Dual 5-Pin Female DIN
Voltage
220-240V UK
Voltage Requirements
100-240 VAC, 50-60 Hz
Connectivity
USB-C®
Supported Sample Rates
44.1, 48, 88.2, 96, 176.4, 192 kHz (kHz)
Height
1.75" (44.45 mm)
Depth
5.5" (140 mm)
Width
12.5" (317.5 mm)
Weight
3.2 lbs (1.5 kg)
